Module Type:High-Density Mixed-Signal I/O

Interface:PXI

Analog Input Channels:32 differential channels

Analog Output Channels:4 channels

Sampling Rate:Up to 1 MS/s per channel

Resolution:16-bit

Voltage Range:+/-10 V

Connectors:4-slot PXI/PXIe

Operating Temperature Range:-40 to +85 °C

Power Requirements:Typically 5 V DC

Compatibility:NI-SignalExpress, LabVIEW, TestStand

    The National Instruments PXI-6221 is a cutting-edge solution for industrial automation and control systems. Featuring 32 differential digital I/O channels, 16 analog input channels, and 8 analog output channels, this module is perfect for complex test and measurement applications. With a sample rate of up to 2 MS/s per channel and 16-bit resolution for analog inputs, you can achieve precise and reliable data acquisition. Its 32-bit digital I/O ensures robust communication and control. Compatible with PXI/PXI Express chassis, the PXI-6221 integrates seamlessly into existing systems. Supported by powerful software like NI LabVIEW and NI Measurement Studio, this module simplifies development and deployment. Its compact design allows for dense packing in rack-mounted systems, maximizing space efficiency. Ideal for applications requiring high density and mixed signal handling, the PXI-6221 offers unmatched performance and flexibility.
