Control Power nominal:20 VA

maximum:65 VA

Control Power Input Range:110 to 250 VDC, 100 to 240 VAC at 50/60 Hz

Dimensions:approx. 12 in H x 5 in W x 8 in L

Weight:approx. 4.5 kg

Ground Current Input Frequency:20 to 100 Hz

Insulation Class:I

Phase Current Input Conversion:True RMS, 1.04 ms/sample

Metering Capabilities:Event reports, waveform captures, startup data logging, and optional metering package

    The GE 369-HI-R-M-0-D-0-E is a cutting-edge motor management relay that enhances motor reliability and efficiency in industrial settings. By integrating advanced monitoring features such as waveform capture and event reporting, this relay provides valuable insights into motor health, helping to prevent unexpected failures and minimize downtime.

    Designed with robust engineering, the relay offers superior performance under various environmental conditions, including high humidity environments up to 95% non-condensing. Its compact size and lightweight design make it ideal for integration into existing systems without compromising space or weight constraints.

    Key features include the ability to capture detailed waveform data and log startup information, which allows operators to perform comprehensive analysis and predictive maintenance tasks. Additionally, the relay’s versatile communication options via RS232 and RS485 ports facilitate seamless integration with other control systems.

    With its advanced metering capabilities and built-in protection functions, the GE 369-HI-R-M-0-D-0-E ensures optimal motor performance and extended operational life. The relay supports adjustments for motor inrush current, cooling rates, and acceleration times, providing users with greater flexibility and control over their motor operations.

    In summary, the GE 369-HI-R-M-0-D-0-E is an indispensable tool for any industrial control system aiming to achieve high levels of reliability and efficiency. It offers a comprehensive solution for monitoring, protecting, and optimizing motor performance.
