Module Type:Motion Control Module

Input Voltage:20…28 VDC

Current Consumption:6 A (max)

Control Outputs:4-axis, up to 400 kHz each

Positioning Accuracy:±0.01%

Communication Interface:CANopen, EtherCAT, PROFINET

Operating Temperature Range:-25°C to +60°C

Storage Temperature Range:-40°C to +85°C

Enclosure Rating:IP67

Weight:1.5 kg

    The Elau SM140/30/120/P0/44/R1/B1/01 represents the pinnacle of industrial drive technology, designed to meet the rigorous demands of modern automation. With its high power output and voltage range, this module provides unmatched precision in motion control, ideal for a wide range of applications including packaging, material handling, and assembly lines. The modular design allows for easy customization and integration with existing systems. Constructed with robust materials and featuring an IP65 enclosure rating, this drive system is built to withstand harsh industrial environments. The cooling method ensures optimal performance even under continuous operation. Utilizing the advanced communication interface and control mode, users can seamlessly integrate this drive into their automation solutions. Installation is straightforward, thanks to clear and comprehensive instructions provided with each unit.
