Module Type:IGBT Module

Application:One Phase

Voltage Rating:600V

Current Rating:100A

Operating Temperature:-40°C to +125°C

Package:Half Bridge

Isolation Voltage:2500V

Switching Frequency:Up to 20kHz

Thermal Resistance:2.5°C/W

    This IGBT module from A-B is designed for one-phase applications, ensuring efficient and reliable power conversion in various industrial settings. With a rated voltage of 600V and a current capacity up to 100A, this module is capable of handling demanding industrial environments. Its wide operating temperature range of -40°C to +100°C makes it suitable for use in extreme conditions. The module features an insulation class F, which provides excellent protection against electrical stresses. Additionally, its thermal resistance of 1.5°C/W ensures effective heat dissipation, enhancing the module’s overall performance and longevity. The through-hole mounting style allows for secure installation on PCBs. This product is ideal for industrial automation systems requiring robust and reliable power management solutions.
